Wear resistant Epoxy Compound - Epoxy used to create a wear resistant face on metal surfaces.

FR985B - ABRASION RESISTANT GELCOAT

Eli-Cote FR/985 is a blue coloured Epoxy Gelcoat with good abrasion resistance.

Mixing and Application

WORK TEMP

WORK TIME

GEL TIME

CURE TIME

60ºC

10 min

25 min @ 5mm

2 hrs @ 1mm

APPLICATION:

Brush

VISCOSITY / 25°C:



MIXING RATIO:

By Weight:

By Volume:


17 Parts Hardener

26 Parts Hardener


100 Parts Resin

100 Parts Resin

COLOUR:

Blue

COVERAGE/585g pack

0.4 m2 (1 mm thick coating)

FR1008D - Wear resistant Epoxy Compound

The Eli-Cote FR/1008/D has been designed for the protection of surfaces subjected to high wear, particularly on areas where solids or slurries cause severe abrasion. The mortar provides a long lasting lining to metal and concrete surfaces. The soft thixotropic texture of the mortar allows for easy mixing and makes the product suitable for horizontal, as well as vertical applications. Typical applications include wear resistant lining for chutes, pump casings, slurry pumps, impellers, fans, pipe elbows, hoppers, vibrating feeders, etc.

Mixing and Application

WORK TEMP

WORK TIME

GEL TIME

CURE TIME

75ºC

15 min

60 min

 3 hrs

APPLICATION:

By spatula, trowel or hand (use protective gloves)

VISCOSITY / 25°C:

Thixotropic Paste


COLOUR:

Resin:

Black


Hardener:

Iron Oxide Red


Mixed colour:

Brown

MIXING RATIO:

100 Parts Resin

50 Parts Hardener

COVERAGE:

1 Litre  = 1.9 kg / m2 (1 mm)


6 Litres = 111.4 kg / 6m2 (1 mm)

FR1013 - Wear resistant Epoxy Compound

The Eli-Cote FR/1013 has been designed for the protection of surfaces subjected to high wear, particularly on areas where solids or slurries cause severe abrasion. The mortar provides a long lasting lining to metal and concrete surfaces.

The soft thixotropic texture of the mortar allows for easy mixing and makes the product suitable for horizontal, as well as vertical applications.

Mixing and Application

WORK TEMP

WORK TIME

GEL TIME

CURE TIME

100ºC

15 min

25 min @ 5mm

40 min @ 5mm

APPLICATION:

By spatula, trowel or hand (use protective gloves)

VISCOSITY / 25°C:



COLOUR:

Resin:

Grey (Paste)


Hardener:

Brown – Transparent (Liquid)


Mixed colour:

Grey (Paste)

MIXING RATIO:

100 Parts Resin


By Weight or Volume:

6 Parts Hardener (Weight)


13 Parts Hardener (Volume)

COVERAGE

1 Litre  = 2 kg / m2 (1 mm)

6 Litres = 12 kg / 6m2 (1 mm)

FR1008HT3 - ABRASION & HEAT RESISTANT MORTAR

The Eli-Cote FR/1008HT3 has been designed for the protection of surfaces subjected to high wear, particularly on areas where solids or slurries cause severe abrasion. The mortar provides a long lasting lining to metal and concrete surfaces.

The soft thixotropic texture of the mortar allows for easy mixing and makes the product suitable for horizontal, as well as vertical applications.

Mixing and Application

WORK TEMP

WORK TIME

GEL TIME

CURE TIME

120ºC

20 min

1½ – 1¾ hrs   @ 5mm

12 Hours

APPLICATION:

By spatula, trowel

VISCOSITY / 25°C:



COLOUR:

Resin:

Grey


Hardener:

Black


Mixed colour:

Metal grey

MIXING RATIO:

By Weight or Volume:


100 Parts Resin


25 Parts Hardener

COVERAGE

1.85 – 1.9 g/cm3

FR1008D1LV - ABRASION RESISTANT MORTAR

The Eli-Cote FR/1008/D1/LV has been designed for the protection of surfaces subjected to high wear, particularly on areas where solids or slurries cause severe abrasion. The mortar provides a long lasting lining to metal and concrete surfaces.

The soft thixotropic texture of the mortar allows for easy mixing and makes the product suitable for horizontal, as well as vertical applications.

A two part, ambient temperature curing Epoxy Repair/Maintenance Compound containing abrasion resistant fillers

WORK TEMP

85ºC

Mixing and Application

WORK TIME

GEL TIME

CURE TIME

15 min

30 min

10 hours

APPLICATION:

By spatula, trowel or hand (use protective gloves)

VISCOSITY / 25°C:



COLOUR:

Resin:

Grey (Paste)


Hardener:

Brown – Transparent (Liquid)


Mixed colour:

Grey (Paste)

MIXING RATIO:

By Weight:

By Volume:


100 Parts Resin

100 Parts Resin


30 Parts Hardener

35 – 37 Parts Hardener

COVERAGE

1 Litre  = 1.95 kg / m2 (1 mm)

3 Litres = 3 kg / 3m2 (1 mm)
